KISANKRAFT CENTRIFUGAL ELECTRIC WATER PUMP KK-WPE-1500F

Brand: Kisan Kraft | Model: KK-WPE-1500F | Product Type: Electric Centrifugal Water Pump | Rated Power: 1.5 kW (2 HP) | Maximum Flow Rate: 600 L/min

Product Description

The Kisan Kraft KK-WPE-1500F Centrifugal Electric Water Pump is designed for agricultural water transfer, drainage, and other suitable water-management applications. It features a powerful electric motor and a centrifugal pumping mechanism for moving water in compatible agricultural and general-purpose installations.

The pump operates at a rated power of 1.5 kW (2 HP) and a speed of 2,850 RPM. According to the manufacturer’s specifications, it offers a maximum flow rate of 600 litres per minute and a maximum pumping head of 15 metres. It features copper motor winding, a cast-iron pump body and impeller, and a 6-metre power cable with plug. <Cite refs={[“turn255931search12″,”turn255931search2”]}/>

The Kisan Kraft KK-WPE-1500F is designed for submerged pumping applications, with a listed maximum immersion depth of 5 metres and an IP68 protection rating. It is suitable for compatible farm water-management and water-transfer tasks when installed and operated according to the manufacturer’s instructions. Actual flow depends on the pumping head and operating conditions.

Key Features

• Brand: Kisan Kraft
• Model: KK-WPE-1500F
• Product Type: Electric Centrifugal Water Pump
• Rated Power: 1.5 kW (2 HP)
• Operating Speed: 2,850 RPM
• Maximum Flow Rate: 600 L/min
• Maximum Head: 15 metres
• Minimum Head: 6.5 metres
• Electrical Supply: 220–240V, 50Hz
• Rated Current: 10.2 A
• Motor Winding: Copper
• Pump Body and Impeller: Cast iron
• Protection Rating: IP68
• Maximum Immersion Depth: 5 metres
• Power Cable: 6 metres with plug
• Pump Delivery Size: 2 inches

Product Benefits

• High-Capacity Water Transfer: The listed maximum flow rate of 600 L/min supports suitable high-volume water-transfer applications.
• Powerful Motor: The 1.5 kW (2 HP) motor is designed for pumping tasks within the specified operating range.
• Robust Construction: Cast-iron pump components provide a sturdy construction for intended water-pumping applications.
• Copper Motor Winding: Supports reliable motor performance when operated within the manufacturer’s specifications.
• Submersible Design: The IP68 protection rating and specified immersion depth support compatible submerged installations.
• Convenient Electrical Connection: The supplied 6-metre power cable supports suitable installation arrangements.
• Agricultural Versatility: Useful for compatible water-transfer and drainage tasks on farms and other properties.
• Practical Pumping Head: The maximum head of 15 metres helps users evaluate the pump for their intended installation.

Technical Specifications

Applications

• Agricultural water transfer
• Farm water-management operations
• Suitable irrigation-related water handling
• Water transfer from compatible tanks and reservoirs
• Drainage from suitable flooded areas
• Garden and landscape water management
• Submerged water-pumping applications
• General water-transfer tasks within the rated operating limits

Usage and Maintenance

1. Check Electrical Compatibility: Ensure the power supply meets the pump’s voltage, frequency, and current requirements.
2. Inspect the Power Cable: Check the cable and plug for damage before operation.
3. Install Correctly: Position the pump according to the manufacturer’s instructions and do not suspend it by its cable.
4. Check Water Conditions: Operate within the specified liquid-temperature and immersion limits.
5. Prevent Dry Running: Ensure the pump is submerged as required by the manufacturer’s instructions before switching it on.
6. Use Electrical Protection: Ensure suitable earthing and residual-current protection are provided by a qualified electrician.
7. Monitor Operation: Stop the pump if unusual noise, vibration, or abnormal performance occurs.
8. Disconnect Before Servicing: Isolate the electrical supply before cleaning or inspection.
9. Clean Regularly: Remove dirt and debris according to the manufacturer’s maintenance instructions.
10. Arrange Authorized Servicing: Have electrical or internal pump repairs carried out by an authorized service provider.

Product Category

Agriculture & Farming > Irrigation Equipment > Electric Water Pumps
