KISANKRAFT CENTRIFUGAL ELECTRIC WATER PUMP KK-WPE-2200F

Brand: Kisan Kraft | Model: KK-WPE-2200F | Product Type: Electric Centrifugal Water Pump | Rated Power: 2.2 kW (3 HP) | Maximum Flow Rate: 600 L/min

Product Description

The Kisan Kraft KK-WPE-2200F Centrifugal Electric Water Pump is designed for agricultural water management, water transfer, and other suitable pumping applications. Powered by an electric motor with copper winding, it is intended for moving water in compatible farm and industrial installations.

The pump has a rated power of 2.2 kW (3 HP) and a listed operating speed of 2,850 RPM. Its maximum flow rate is 600 litres per minute, with a maximum pumping head of 17 metres. These specifications help users assess the pump’s suitability for their water-transfer requirements. <Cite refs={[“turn238406search2″,”turn238406search6”]}/>

The Kisan Kraft KK-WPE-2200F requires a compatible electrical supply and suitable installation. Published product information identifies this model as a three-phase, 380V electric water pump. Before purchasing, verify the electrical connection, discharge requirements, pumping head, and installation conditions to ensure compatibility with your application.

Key Features

• Brand: Kisan Kraft
• Model: KK-WPE-2200F
• Product Type: Electric Centrifugal Water Pump
• Rated Power: 2.2 kW (3 HP)
• Operating Speed: 2,850 RPM
• Maximum Flow Rate: 600 L/min
• Maximum Head: 17 metres
• Electrical Supply: 380V, 50Hz, three-phase
• Motor Winding: Copper
• Insulation Class: Class B
• Protection Rating: IP68, as listed for this model in product catalogue information
• Pump Delivery Size: Confirm with the manufacturer
• Application: Agricultural water transfer and water management

Product Benefits

• High-Capacity Water Transfer: The listed maximum flow rate of 600 L/min supports suitable high-volume water-moving tasks.
• Powerful Electric Motor: The 2.2 kW (3 HP) rating supports pumping applications within the specified operating range.
• Copper Winding: Designed to support dependable motor performance when operated according to manufacturer instructions.
• Practical Pumping Head: The maximum head of 17 metres helps users assess suitability for their installation.
• Agricultural Applications: Suitable for compatible farm water-management and water-transfer requirements.
• Electric Operation: Provides powered water pumping without requiring a petrol or diesel engine.
• Installation Planning: The listed motor specifications help users plan an appropriate three-phase electrical connection.

Technical Specifications

Applications

• Agricultural water transfer
• Farm water-management operations
• Suitable irrigation-related water pumping
• Water transfer from compatible tanks and reservoirs
• Agricultural drainage where the pump is suitable for the water conditions
• Water supply for suitable farm installations
• General water-transfer tasks within the rated operating limits

Usage and Maintenance

1. Verify the Electrical Supply: Confirm that a 380V three-phase supply is available and compatible with the pump.
2. Arrange Proper Installation: Have the pump installed by a qualified technician according to the manufacturer’s instructions.
3. Inspect Connections: Check electrical connections, discharge piping, and mounting arrangements before use.
4. Check Water Conditions: Confirm that the liquid and operating conditions fall within the manufacturer’s specified limits.
5. Avoid Dry Running: Operate the pump according to the required priming or immersion instructions for its design.
6. Monitor Performance: Stop the pump if unusual noise, vibration, overheating, or reduced flow occurs.
7. Disconnect Before Servicing: Isolate the electrical supply before inspection, cleaning, or maintenance.
8. Clean as Required: Remove dirt and debris according to the manufacturer’s maintenance guidance.
9. Follow Electrical Safety Practices: Use appropriate earthing, overload protection, and other electrical safeguards as specified by a qualified electrician.
10. Use Authorized Service: Refer motor or internal pump repairs to a qualified service provider.

Product Category

Agriculture & Farming > Irrigation Equipment > Electric Water Pumps
